STA115 Rotary Swaging Machine

In stock
SKU
STA115
£295.00 £245.83
Calculate UK Shipping below

STA115 Rotary Swaging Machine

Universal Swaging Machine will perform a multitude of rotary operations in sheet metal up to 1.0mm and 177mm deep. When fitted with the appropriate wheels, operations including wiring, swaging, crimping and closing can be achieved.

The pressure is set by means of a top mounted hand crank and the top beam can be kept parallel by adjusting the rear nut which raises and lowers the rear of the top beam. The top beam can also be adjusted in an out by moving the knob at the rear of the body for different operations.  An extension gauge lets you set the depth & it comes complete with 6 sets of wheels and a bench clamp that swivels the machine to a convenient working position. Its a pleasure to use and great finishes can be achieved in no time.

The photos show just a few of the basic operations achievable.

Features:

• Cast iron construction
• Formers included for jennying, swaging, wiring, crimping, joggling and closing
• Adjustable roll pressure by means of top mounted hand crank
• Can be used in both forward and reverse
• Operation is smooth, fast and precise
• Table mount with clamp is standard



ModelSTA115
Die Set 1Shrinking Die
Die Set 2Ogee Bead (Total width 15mm)
Die Set 3Wiring, Closing or Bead Forming (produces 5mm bead)
Die Set 4Wiring, Closing or Bead Forming (produces 6.5mm bead)
Die Set 5Tipping with Backstop
Die Set 6Tipping without Backstop
Throat Depth177mm (7")
Capacity Steel1.0mm
Capacity Aluminium1.6mm





Packing Dimensions (cm)49x46x16
Weight25kg
